LiftMaster Access Control
LiftMaster Products
Whether you have a single-family home, apartment/condo, or live in a gated community, or have a commercial property our Access Control Systems give you multiple options for managing your access points. With entry systems to keypads, card readers to perimeter alert systems, our lineup of feature-rich options provides the perfect access solution for your needs.
Access Control
CAPXL Connected Access Portal, High Capacity
FEATURES
Smart
Easy to Use Display
Navigation is Intuitive and Screen Has a Customizable Background.
Remote Programming
and activity monitoring using LiftMaster Cloud.
Configurable Email Notifications
Know when codes are overused or if service is needed for the CAPXL, CAP2D or gate operator.
No Need To Dig Up Driveway or Yard
with Wi-Fi® and wireless link to UL 325 LiftMaster Gate Operators with new firmware 4.2
Reliable and Secure
Voice Over IP (VoIP)
provides crystal-clear call quality with no long-distance charges.
Modern, Durable Design
Elegant Stainlesss Steel Brushed Finished Front.
Entry Even When the Internet is Down
Local System Memory allows entry even when the internet is down.
Real-Time Activity Tracking and Alerts
for example, when a suspended code is used or if an active code is being overused.
Keeps Data Protected
and Safeguards Resident Information with Cloud-Based Security.
Connectivity
Multiple Ways to Connect CAPXL to LiftMaster Cloud
•Wi-Fi
•Cellular
•Wired High-Speed
•DSL
LiftMaster Connected Access Portal
LiftMaster CAPXL and CAP2D with LiftMaster Cloud™, access control for residential communities. Smart technology. Remote access. Consistent uptime.
SPECIFICATIONS
Local User Capacity50000Event History50000Max Number Of Gates/Doors of control (Each)4Wiegand Input4Relay Output8 (4 Primary, 4 Auxilliary)ConnectivityVoIP (Phone.com) using Wi-Fi/Cellular/Wired High-Speed Internet/DSLSoftwareLiftMaster Cloud™Display Type10 Inch Full Color Touch ScreenDimensions18"H x 14"W x 4.5"DOperating Temperature-20°F to 130°F (-29°C to 54°C)
WARRANTY
- Accessory Warranty: 2 years
LiftMaster CAP2D
FEATURES
Smart
Universal Compatibility
Use with 26-Bit and 30-Bit Wiegand-Compatible Readers, Receivers and RFID Readers.
Remote Programming
and activity monitoring using LiftMaster Cloud.
Configurable Email Notifications
Know when codes are overused or if service is needed for the CAPXL, CAP2D or gate operator.
Flexibility of Device Placement
No Wiring Between Controllers and Power Over Ethernet.
Reliable and Secure
Keeps Data Protected
and Safeguards Resident Information with Cloud-Based Security.
Real-Time Activity Tracking and Alerts
for example, when a suspended code is used or if an active code is being overused.
Entry Even When the Internet is Down
Local System Memory allows entry even when the internet is down.
Data Over Internet
provides reliable communication of all access activity.
Compact Size
Easily fits In Standard Locations.
Connectivity
Multiple Ways to Connect CAP2D to LiftMaster Cloud
•Cellular
•Wired High-Speed
•DSL
SPECIFICATIONS
Local User Capacity25000Event History6000Max Number Of Gates/Doors of control (Each)2Wiegand Input2Relay Output4 (2 Primary, 2 Auxilliary)ConnectivityData Only using Cellular/Wired High-Speed Internet/DSLDisplay TypeLiftMaster Cloud™Operating Temperature+32°F to 149°F (0°C to 65°C)
WARRANTY
- Accessory Warranty: 2 years
EL2000SS
FEATURES
Smart
Easy to Use and See
With Illuminated Call Button and Keypad
Remote Programming with Versa
and Free Cloud Storage with Versa XS 4.0 Software.
Convenient Access Management
Make Updates or Latch/Unlatch Doors From Your Windows-Based Computer.
Reliable and Secure
Uses Existing Landline
No additional monthly expenses.
Safeguards Resident Information
and keeps data protected with Cloud Storage Security.
Modern, Durable Design
Elegant Stainlesss Steel Brushed Finished Front.
Connectivity
Multiple Ways to Connect for Voice Communication
• POTS (Telephone Line)
• Filtered DSL
SPECIFICATIONS
Local User Capacity2000Event History8000Max Number Of Gates/Doors of control (Each)4Wiegand Input4Relay Output4 Primary RelaysConnectivityPOTS/Filtered DSL using Dial-up Modem/Direct Connect/KeypadSoftwareVersa XS 4.0Display Type5 Inch Monochromatic ScreenDimensions16"H x 11.25"W x 3.25"DOperating Temperature-4°F to 149°F (-20°C to 65°C)
WARRANTY
- Accessory Warranty: 2 years
EL25
FEATURES
Smart
Easy to Use and See
With Illuminated Call Button and Keypad
Remote Programming with Versa
and Free Cloud Storage with Versa XS 4.0 Software.
Convenient Access Management
Make Updates or Latch/Unlatch Doors From Your Windows-Based Computer.
Reliable and Secure
Uses Existing Landline
No additional monthly expenses.
Rugged, Vandal Resistant Design
with no LCD display.
Safeguards Resident Information
and keeps data protected with Cloud Storage Security.
Connectivity
Multiple Ways to Connect for Voice Communication
• POTS (Telephone Line)
• Filtered DSL
SPECIFICATIONS
Local User Capacity2000Event History8000Max Number Of Gates/Doors of control (Each)4Wiegand Input4Relay Output4 Primary RelaysConnectivityPOTS/Filtered DSL using Dial-up Modem/Direct Connect/KeypadSoftwareVersa XS 4.0Dimensions6"H x 10.25"W x 4"DOperating Temperature-4°F to 149°F (-20°C to 65°C)
WARRANTY
- Accessory Warranty: 2 years
